The Digital Imaging and Communications in Medicine (DICOM) standard is a key component of contemporary medical imaging technology.
DICOM began as a joint effort between the National Electrical Manufacturers Association (NEMA) and the American College of Radiology (ACR) in the early 1980s. [1] Its main goal was to establish a framework for the reliable and consistent sharing, storing, and transferring of patient data and medical images across multiple digital imaging systems.
DICOM facilitates the efficient communication of medical imaging equipment and software from various manufacturers. The software establishes a standardized methodology, guaranteeing a smooth clinical workflow across departments.
As a result, this standard for imaging and communications is gathering more and more attention from investors. In 2023 DICOM was valued at $ 16.2 billion and is projected to rise to $ 33.8 billion by 2032. [2]
DICOM standard overview
The DICOM standard dictates how data must be stored in specific data structures. The idea is to make it more usable for professionals across the field.
Furthermore, DIMCOM includes specific communication protocols. They dictate how data is to be transferred between professionals or healthcare facilities.
The standard also regulates what DICOM image formats must be used. Below is a breakdown of this multi-layered structure.
Data structure and DICOM objects
DICOM’s Data Structure arranges medical imaging data into standardized units known as DICOM data objects. These items serve as the cornerstone of DICOM files, facilitating effective retrieval, digital storage, and interpretation across various healthcare systems.
DICOM files are ordered in a hierarchical organization and contain both the image data and crucial patient information needed for contextual comprehension.
DICOM is essential to clinical workflows in hospitals, radiology centers, and imaging facilities because it facilitates the precise exchange of medical imaging data between various devices and systems.
Each DICOM data object consists of two main components: the header (or metadata) and the image data itself. These include important details like the patient’s name, ID, study description, imaging modality, and acquisition.
These metadata components guarantee that it can be correctly linked to the appropriate patient and medical record by giving the image context. The actual visual information, or pixel data, that was recorded by the imaging device, is contained in the image data. In a high-resolution CT or MRI scan, for example, this enables the DICOM object to carry detailed visual data appropriate for in-depth analysis and diagnosis.
Each DICOM data object contains numerous data elements, each with its own tag, value representation (VR), value length, and value field. While the VR indicates the type of data (text or integer), the tag serves as a unique identifier.
Each DICOM file is a complete record of the image and its pertinent medical information since the value field includes the actual data, such as patient demographics or scan details.
This structure guarantees that all image data is enhanced through metadata offering smooth compatibility across various medical imaging devices. Furthermore, medical professionals interpret data accurately through DICOM communication systems.
Service object pairs
A key idea in the DICOM Standard are the Service Object Pairs (SOPs), which specify particular services that make it easier to handle, store, and send medical data and images.
A DICOM service and an information object associated with a specific imaging task are paired in each SOP. The DICOM Store Service, for instance, makes it possible to store DICOM files in a Picture Archiving and Communication System (PACS). This pairing guarantees that medical images are safely kept and easily available when required.
Furthermore, DICOM Print Service permits printing relevant images straight from the imaging system. This functionality facilitates the production of hard copies for patient records or consultations. SOPs are very effective at managing a variety of imaging processes because they pair services with particular object types.
Certain SOPs are essential for automating and safeguarding workflows. For example, the DICOM Storage Commitment Service certifies that an image has been successfully stored and is accessible for later use.
Another essential SOP is The DICOM Modality Worklist Service (MWS). The MWS simplifies data entry by enabling imaging systems to retrieve scheduled exams and automatically fill in the patient’s details and exam specifics. This automation improves workflow efficiency and minimizes errors by reducing manual entry.
Consequently, the SOPs make it possible for DICOM to smoothly integrate across various imaging devices and DICOM networks. This integration ensures that all imaging tasks are carried out precisely and consistently regardless of the device or manufacturer.
Data communication protocols
DICOM’s data communication protocols make it possible for healthcare systems to exchange data easily. Fast and secure transfers over local and wide networks are made possible by DICOM’s protocol, which is layered over TCP/IP.
This configuration guarantees seamless transfer of patient data and medical images between various devices. DICOM facilitates real-time data exchange through this protocol, which is crucial in settings where prompt imaging access is necessary.
DICOM communication protocols connect imaging modalities, PACS servers, and workstations in a unified DICOM network. These protocols allow services such as the DICOM Store Service and DICOM Modality Worklist Service to run smoothly.
For example, a DICOM Store request can securely send and save images to a PACS server, allowing them to be shared across departments. The communication protocol also enables healthcare providers to access and share DICOM files remotely, facilitating collaborative patient care across sites.
DICOM vs. Other imaging standards
DICOM is frequently compared to other digital imaging standards such as JPEG, PNG, and TIFF, but its application in healthcare far outperforms these general-purpose formats.
The primary distinction is DICOM’s ability to manage medical data alongside medical images. Unlike JPEG and PNG files, which only contain visual data, DICOM files include embedded image metadata that describes the patient, procedure, and imaging modality.
The dcm file extension is specific to DICOM and indicates that it is a medical file that requires specialized DICOM viewing software.
While JPEG and PNG may be adequate for basic image sharing, they cannot meet the detailed medical imaging information and image management requirements of healthcare. Thus, DICOM remains the industry standard in radiology and other diagnostic fields that require precise image data and patient context.
Key features of the DICOM image standard
The framework created by the DICOM standards supports seamless integration across devices and works based on these functionalities:
Automated workflows
The DICOM Modality Worklist Service is an extremely useful tool for streamlining workflows in medical imaging departments. This service enables image acquisition to devices, such as CT and MRI scanners. The devices automatically retrieve a list of scheduled exams from the hospital or radiology information system. It pre-fills the DICOM file with patient and exam information as soon as the scan begins.
This automation reduces the need for manual data entry, lowering the risk of errors and saving significant time for technologists. It ensures that all medical images captured are correctly associated with the appropriate patient and study. These measures improve both efficiency and data accuracy.
Pixel data encoding and image display consistency
DICOM encodes pixel data in a highly specific manner. The encoding aims to ensure that DICOM images display consistently across multiple devices and software.
Unlike other formats that compress or alter image quality, the DICOM format includes detailed instructions for interpreting pixel values. These instructions allow images to maintain diagnostic quality.
This level of precision is critical in diagnostic imaging fields. It ensures that fine details—which are necessary for identifying pathologies—are not lost or altered. DICOM also supports grayscale and color images, making it suitable for a wide range of imaging applications.
Supported images vary from simple X-rays to more complex MRI or PET scans.
DICOM print service for consistent image reproduction
The DICOM Print Service enables the direct printing of images from imaging devices to DICOM-compliant printers. This ensures that printed images maintain the same quality, scale, and detail as their digital counterparts. Effective image reproduction is essential for accurate physical records or when consulting with patients in person.
Unlike generic printing solutions, DICOM-compliant printers adhere to specific standards for medical image reproduction. The standard maintains restrictions on brightness, contrast, and annotations. This feature is especially useful for radiologists and specialists who require high-quality printed images for physical documentation.
DICOM storage commitment
DICOM services are intended to provide secure and dependable storage of DICOM files on a PACS server. This service goes beyond basic storage by confirming that images and related data have been securely stored and can be retrieved in the future.
This confirmation is critical for regulatory compliance, especially when dealing with sensitive patient data that must be stored for years. Storage Commitment also encourages data redundancy, which means making backups to avoid data loss. These backups are critical for disaster recovery and long-term patient care records.
Flexible image compression options
DICOM provides both lossless and lossy compression options for DICOM images. The aim is to help manage storage requirements while maintaining diagnostic quality.
Lossless compression preserves 100% of the original data. This preservation ensures no loss of image quality, which is critical for high-detail scans such as MRIs.
Lossy compression, on the other hand, reduces the file size by selectively reducing certain data. Such compression may be acceptable for non-diagnostic purposes or images viewed on mobile devices.
This flexibility in compression options allows healthcare facilities to balance storage costs with image quality. The result is optimization of resources while preserving the integrity of medical imaging for different clinical needs.
These practical applications of DICOM are the reason why the market size of software is predicted to grow at such a rate. However, the software solution is not without its drawbacks.
Some concerns with DICOM
As with every healthcare software, some concerns need to be addressed.
Security and patient privacy
A major issue that must be addressed when talking about DICOM is the possible security threats.
- Concern:
DICOM files contain sensitive patient data. This data makes them an appealing target for unauthorized access, hacking, and data breaches. Cybercriminals can exploit this data, particularly as healthcare systems transition to cloud-based storage and networking.
- Solution:
Implementing strict security protocols is critical. Facilities should encrypt data in transit and at rest so that only authorized personnel can access DICOM files. Measures that achieve this protection include Secure Access Management (SAM) systems and Multi-Factor Authentication (MFA). Healthcare facilities must also undergo regular security audits and vulnerability assessments. These measures are essential for identifying potential weaknesses in the DICOM network.
Additional measures to protect from unauthorized access include Virtual Private Networks (VPNs) and firewalls.
Data storage and file size challenges
Another important area to focus on is the storage of data.
- Concern:
DICOM images are large and can quickly fill storage space, particularly those from high-resolution imaging modalities such as MRI or CT scans. Managing these large amounts of data can result in rising costs and potential delays in data retrieval and clinical workflow.
- Solution:
Healthcare providers can use DICOM-compliant compression techniques to address these storage issues. Investing in lossless compression maintains image quality where exact storage is needed. Whereas lossy compression can reduce file sizes for non-diagnostic images, saving space.
Additionally, many facilities are implementing cloud-based storage solutions to alleviate some storage demands from local servers.
Lack of support for emerging imaging technologies
While DICOM is already an established technology, developers must constantly monitor how DICOM interacts with new technologies.
- Concern:
DICOM was originally designed for traditional imaging formats such as X-ray, MRI, and CT. However, technologies such as functional MRI (fMRI), 3D ultrasound, and AI-based diagnostic tools are constantly emerging and may lack direct DICOM support. This lack of support may impede the implementation of innovative imaging techniques in hospitals. This is especially true for hospitals that rely heavily on DICOM for image management.
- Solution:
The DICOM standard is continuously evolving, and updates often incorporate support for new technologies. Healthcare providers can collaborate with industry groups and contribute to the DICOM Standards Committee to advocate for new feature inclusion. In the meantime, some facilities use custom data conversion tools or middleware that allow new formats to be converted into DICOM-compatible formats. This ensures that new data types can be stored and viewed within existing DICOM-based systems, preserving interoperability.
It is important not to shy away from these challenges but as the article demonstrates – all of these issues can be overcome. The result is a practical technology, with a promise for applications in the real world.
Discover how we can help outsource Healthcare projects efficiently Speak to an expert today, and see how our on-demand IT talent and augmented teams can efficiently deliver value at every step of your roadmap.
Practical аpplications of DICOM
The main applications of the software are in the fields of cross-department sharing, telemedicine, nuclear medicine, and image fusion.
Cross department sharing
DICOM is essential in a variety of medical imaging settings. It allows for efficient and standardized imaging data management.
An excellent example of DICOM software in the field are PACS. The software uses DICOM to store, retrieve, and organize files between departments. PACS enable seamless access to medical images from various imaging systems like CT, MRI, X-ray, and ultrasound.
The result is an improved workflow and interoperability. DICOM allows imaging devices from a variety of manufacturers. The software can connect, share, and manage data seamlessly. For example, radiologists and clinicians can instantly access and share images from any location, accelerating diagnosis
Telemedicine and remote consultations
DICOM is essential in telemedicine and remote consultations, as DICOM files enable specialists to review and analyze medical images from multiple facilities. This capability enables faster, more collaborative patient care and ensures that specialists can help with diagnoses from a distance.
DICOM viewers play an important role in this process, allowing for clear, detailed image visualization on a variety of devices for effective remote analysis.
In radiology departments, DICOM integration with DICOM modality worklist services automates the process of linking patient and study information to imaging exams, reducing manual data entry errors and improving data accuracy.
Nuclear Medicine
DICOM also plays an important role in nuclear medicine, where it manages complex image sequences that require thorough analysis. DICOM integrates these images into a unified DICOM network and allows for a comprehensive view of the patient’s medical history.
In oncology, DICOM allows clinicians to compare images over time to track treatment progress and effectiveness. A DICOM image format allows high-quality images to be accessed, compared, and shared without losing diagnostic information.
Image fusion
DICOM’s detailed data structure is beneficial for image fusion applications, which combine data from multiple imaging modalities such as PET and MRI. This standardization allows data from various modalities to be combined into a single, enhanced image, providing deeper diagnostic insight.
DICOM also supports DICOM storage commitment services, which ensure the long-term storage of critical DICOM files and make them retrievable for future use. This feature is critical for regulatory compliance and data backups.
DICOM promotes better, faster decision-making and better patient outcomes in a variety of healthcare settings by standardizing medical imaging data handling and improving image access across departments.
Conclusion
DICOM is critical in modern healthcare because it allows for the efficient management, storage, and sharing of medical imaging data across multiple modalities and departments. Collaboration with a healthcare software specialist is essential for organizations looking to optimize DICOM workflows and ensure secure, compliant data handling.
